Linear between two supplied anchors
At 20 ft, capacity equals “Max Weight.” At the supplied maximum radius, capacity equals “Weight Full Extend.” The tool does not extrapolate.
C(r) = Wmax + ((r − 20) ÷ (Rmax − 20)) × (Wfull − Wmax)
Preliminary fleet screening
Crane Finder
Enter the hook position and total suspended load to screen the fleet.
01
Required hook height from boom pivot
ft
02
Radius from center of rotation; model starts at 20 ft
ft
03
Include load, rigging, hook block and devices
lb
04
Illustrative planning reserve; confirm your company policy.
Preliminary match
Smallest qualifying model group
AC180
Estimated capacity10,190 lb
Load utilization86.5%
Maximum reach120 ft
Editable rental estimate$1,360
4 billable hours × $340/hour. Weekday base rate with operator included, port-to-port. Overtime, Sundays/holidays, taxes, permits, lift plans, travel and add-ons are not included.
All other qualifying modelsAC200
Screening estimate only.
Linear interpolation is not a manufacturer load chart. A qualified lift professional must verify the exact crane, configuration, deductions, ground conditions, wind and total load before any lift.
02 / TRANSPARENT RESULTS
Every model, every decision.
The prototype keeps source values separate from estimated values and shows why each model passes or fails.
Straight-line geometry
Because height is not present in Sheet2, the tool temporarily treats maximum radius as maximum boom length and checks the diagonal distance.
Lrequired = √(height² + radius²)Smallest qualifying ton class
A model qualifies only when it passes radius, diagonal reach, and planning-utilization checks. Qualifying models are ranked by nominal ton class.
load ÷ estimated capacity ≤ planning utilizationHourly rate with minimum time
Rates begin with the supplied April 1, 2026 sheet and can be changed in Pricing settings. The estimate uses the larger of planned hours or the crane minimum.
estimate = max(planned hours, minimum hours) × hourly rateLIVE FLEET EVALUATION
9 models from Sheet2
| Model | Class | Max reach | Estimated capacity | Utilization | Rate | Screening result |
|---|---|---|---|---|---|---|
| AC87 | 2 ton | 60 ft | — | — | $240/hr | Radius exceeds reach |
| AC80 | 2 ton | 50 ft | — | — | $240/hr | Radius exceeds reach |
| AC167 | 30 ton | 80 ft | 1,391 lb | 634% | $260/hr | Height + radius exceed reach |
| AC170 | 30 ton | 80 ft | 1,391 lb | 634% | $260/hr | Height + radius exceed reach |
| AC168 | 30 ton | 80 ft | 1,391 lb | 634% | $260/hr | Height + radius exceed reach |
| AC160 | 40 ton | 100 ft | 3,782 lb | 233.2% | $280/hr | Height + radius exceed reach |
| AC140 | 40 ton | 100 ft | 3,782 lb | 233.2% | $280/hr | Height + radius exceed reach |
| AC180 | 50 ton | 120 ft | 10,190 lb | 86.5% | $340/hr | Preliminary match |
| AC200 | 50 ton | 135 ft | 11,266 lb | 78.3% | $350/hr | Preliminary match |
Source observations
AC167 / AC170 / AC168 share identical values. AC160 / AC140 also share identical values. AC180 and AC200 share a 50-ton label and 20,000 lb maximum weight but differ at full extension.
Confirm before v1
“Tons” is assumed to be US short-ton class because capacities are in pounds. The attached 38124SHL chart shows a 123.5 ft boom, while the 50128SHL material shows a 128 ft boom and a 50-ton rating at 6 ft. Neither maps conclusively to an AC fleet alias, so Sheet2 remains the active approximation. Browse the Giuffre reference fleet.
